Key Features

• Speedster Disc Alloy Frame
• Speedster Disc Carbon Fork
• Shimano 105 Disc 24 Speed Drivetrain
• Syncros Race 25 Disc Rims
• Schwalbe Lugano Tires




• Shifters

  Shimano 105 ST-R7120 Disc
  Dual control 24 Speed

• Crankset

  Shimano FC-RS520
  50/34

• BB-Set

  Shimano BB-RS500-PB

• Chain

  Shimano CN-M6100-12

• Cassette

  Shimano CS-R7101
  11-34

• Brakes

  Shimano BR-R7170 Hyd.Disc

• Rotor

  Shimano RT-CL700 rotor 160/F and 160/R

• Handlebar

  Syncros Creston 2.0 Compact
  31.8mm

• H'stem

  Syncros RR2.5
  1 1/4", four Bolt 31.8mm

• Seatpost

  Syncros RR2.5 27.2/350mm

• Seat

  Syncros Tofino Regular 2.5

• Headset

  Acros AIF-1133

• Front Hub

  Formula Team II CL Disc 28 H

• Rear Hub

  Formula Team II CL Disc 28 H

• Spokes

  Black 2mm

• Rims

  28 Front, 28 Rear
  Syncros Race 25 Disc

• Front Tire

  Schwalbe Lugano, 700x32C

• Rear Tire

  Schwalbe Lugano, 700x32C

• Approx weight in KG

  10.2

• Approx weight in LBS

  22.49

• Max. System Weight

  120kg
  The overall weight includes the bike, the rider, the equipment, and possible additional luggage.



  				XXS/47		XS/49		S/52		M/54		L/56		XL/58		XXL/61
  A	head tube angle / angle tube de direction			70.5 °		71.0 °		72.0 °		72.5 °		73.0 °		73.3 °		73.3 °
  B	head tube length / hauteur tube de direction			3.7 in		4.1 in		4.8 in		5.6 in		6.4 in		7.2 in		8.0 in
  C	top tube horizontal / longueur horizontale tube supérieur			20.3 in		20.7 in		21.3 in		21.8 in		22.4 in		23.0 in		23.5 in
  D	standover height / hauteur entre-jambes			28.9 in		29.7 in		30.7 in		31.5 in		32.3 in		33.1 in		34.0 in
  E	BB offset / deport axe de pédalier			-2.8 in		-2.8 in		-2.8 in		-2.8 in		-2.8 in		-2.8 in		-2.8 in
  F	BB height / hauteur axe de pédalier			10.8 in		10.8 in		10.8 in		10.8 in		10.8 in		10.8 in		10.8 in
  G	wheel base / entraxe roues			39.4 in		39.7 in		39.8 in		40.0 in		40.3 in		40.6 in		41.1 in
  H	BB center to toptube center / dist. boitier - milieu tube supérieur			16.9 in		17.7 in		18.9 in		19.7 in		20.5 in		21.3 in		22.4 in
  I	BB center to top of seattube / dist. boitier - sommet tube de selle			18.5 in		19.3 in		20.5 in		21.3 in		22.0 in		22.8 in		24.0 in
  J	seat angle / angle tube de selle			75.0 °		75.0 °		74.5 °		74.0 °		73.5 °		73.1 °		73.0 °
  K	chainstay / longueur des bases			16.7 in		16.7 in		16.7 in		16.7 in		16.8 in		16.8 in		16.8 in
  L	reach / reach			14.8 in		15.1 in		15.2 in		15.4 in		15.2 in		15.7 in		16.0 in
  M	stack / stack			20.4 in		20.8 in		21.7 in		22.5 in		23.4 in		24.2 in		24.9 in
  N	stem length / longueur potence			3.3 in		3.3 in		3.7 in		4.1 in		4.1 in		4.4 in		4.4 in
